FLANGES FOR WARP BEAMS
Light metal
alloy or steel zinked flanges in different types and diameters: from 300 to
1600 mm.
Light metal alloy or steel clamping rings.
Type of clamping: radial or axial.
Inside rectified surface.
Light metal alloy flanges with anodizing or epoxy painting treatment by
request.
Steel flanges with electrolitically zinked surface.
Models according to ISO 8116 rule.
Thickness of MOVEABLE or FIXED flanges as per requests or directions of
looms makers.
MOVEABLE
RIBBED FLANGES
max. thickness 85 mm,
for cotton yarn.
with polygonal ribs,
max. thickness 90 mm,
for wool, mixed yarns and
discontinuous synthetic yarns
(spun yarn).
thickness from 85 to 115 mm,
for relaxed synthetic yarns and
technical yarns.
thickness from 85 to 130 mm,
for unrelaxed synthetic yarns,
technical yarns and textile glass yarns.
MOVEABLE DOUBLE WALL FLANGES
Under the same resistance they have inferior deformations and flexions
compared to ribbed flanges.
They are more suitable for fine yarns.
max. thickness 85 mm
for discontinuous synthetic yarns
(spun yarn).
TITAN-H Type (Q4)
max. thickness 85 mm
for continuous synthetic yarns.
FIXED FLANGES FOR HALF BEAMS
thickness from 29 to 40 mm,
for natural yarns.
thickness from 15 to 37 mm,
for synthetic yarns.
